A DIY enthusiast has built a professional-level optical motion capture rig with 16 custom IR cameras, capable of processing 4 billion pixels per second. This project aims to match Hollywood-quality tracking for V-tubing and other applications. The system uses Raspberry Pi compute modules, custom PCBs, and optimized software.
A maker has built a high-performance optical motion capture system using 16 DIY infrared cameras, capable of processing four billion pixels per second. This development aims to provide Hollywood-level tracking precision for V-tubing and other motion capture needs, demonstrating a significant DIY achievement in the field.
The project involves creating 16 custom IR cameras based on AR0234 MIPI sensors, each fitted with M12 lenses and IR filters. These cameras connect to Raspberry Pi compute modules—specifically CM4 or CM5—via custom-designed PCBs that support Power over Ethernet (PoE). Each camera is paired with a near-IR LED ring light pulsing at 160 W, enabling high-quality infrared illumination for precise tracking.
To synchronize the cameras, a pulse-per-second signal is used, ensuring sub-millimeter accuracy in locating motion points. The system employs a proprietary software solution, optimized for speed—reportedly 300 times faster than standard OpenCV processing—and available on GitHub. The entire setup is designed to capture optical motion data at very high speeds, suitable for detailed, real-time V-tubing applications and professional motion capture.
Implications for High-Precision V-tubing and MoCap
This project demonstrates that advanced optical motion capture, traditionally limited to expensive Hollywood studios, can be achieved with a DIY approach. Processing four billion pixels per second with 16 cameras allows for highly detailed and accurate tracking, potentially transforming the accessibility of professional-grade mocap technology for content creators, V-tubers, and researchers. It also showcases the potential for open-source hardware and software solutions to push the boundaries of DIY motion capture systems.
